6F6-W0093-00 6F6-W0093-00-00 6F6-W0093-01
PREMARINE
| Quantity: | |
|---|---|
1. Technical Specifications
| Parameter | Specification / Detail |
| Component Type | Marine Carburetor Overhaul / Rebuild Repair Kit |
| OEM & Interchange Part Numbers | 6F6-W0093-00-00 / 6F6-W0093-00 / 6F6-W0093-01 |
| Engine Configuration | 2-Cylinder 2-Stroke Marine Outboard Engines |
| Horsepower / Displacement | 40 HP 2-Stroke (6F6 / 6F5 / 40J / E40J platform carburetors) |
| Kit Inclusions | Float Chamber Bowl Gasket, Float Needle Valve & Clip Assembly, Valve Seat O-Rings, Float Hinge Pin, Fuel Inlet Filter Screen, and Hardware Washers |
| Material Composition | Ethanol-resistant Viton (FKM) needle tip, Nitrile (NBR) gaskets, marine brass alloy, and stainless steel hardware |
2. Key Features
Complete Rebuild Solution: One-stop maintenance package containing all critical wear items needed to fully disassemble, clean, and reseal the carburetor.
Ethanol & Chemical Resistance: Gaskets and needle valve tips are crafted from high-grade synthetic elastomers engineered to resist swelling, degradation, and hardening caused by modern ethanol-blended marine fuels (E10).
Precise Float & Fuel Level Control: Precision-machined needle valve and resilient Viton tip ensure 100% positive fuel shutoff, eliminating carb flooding and crankcase fuel wash.
Direct OEM Fitment: All gaskets and hardware are manufactured to exact OEM dimensions and tolerances for a perfect, leak-free fit without modification.
3. Compatible Models
Primarily compatible with Yamaha 2-stroke 40 HP outboard carburetor systems:
Yamaha 40 HP 2-Stroke Series: 40J, E40J, 40G, and related 2-cylinder 40HP models built on the 6F6 architecture
Engine Platform: Yamaha 6F6 / 6F5 powerhead carburetor assemblies
4. Aftermarket & Brand Compatibility
OEM Brand Fitment:
Yamaha Marine: Engineered for Yamaha 40HP 2-stroke outboard carburetor fuel systems.
PREMARINE Brand Aftermarket Replacement:
PREMARINE Quality Standard: PREMARINE specializes in high-durability marine fuel and engine overhaul components. This carburetor kit utilizes fuel-resistant Viton rubber and precision-turned brass components.
Direct OEM-Level Performance: Tolerances, fuel-pressure retention, and sealing integrity meet or exceed OEM specifications, restoring original factory throttle response and serving as the premier cost-effective solution for professional marine service shops.
5. Common Symptoms & Troubleshooting
Carburetor Flooding / Fuel Overflowing from Throat:
Cause: Worn groove on the rubber needle valve tip or sediment wedged in the valve seat preventing complete shutoff.
Troubleshooting: Remove the float bowl and inspect the needle valve tip under magnification for ridge wear. Test air shutoff through the fuel inlet nipple by raising the float gently by hand.
Unstable Idle, Stalling, or Hesitation on Acceleration:
Cause: Flattened or hardened float bowl gasket creating an unmetered air leak, or clogged internal inlet screens.
Troubleshooting: Check the bowl gasket for brittleness. Clean all internal passages with carb cleaner and reinstall with the new gasket and filter screen from the kit.
Lean Fuel Condition / Power Loss at High RPM:
Cause: Restricted fuel flow past a sticking needle valve or incorrect float drop/height adjustment starving the high-speed main jet.
Troubleshooting: After rebuilding with new kit components, adjust the float arm height strictly to factory service manual specifications to ensure adequate fuel volume in the bowl.
OEM Part Numbers
Compatible OEM references include:
6F6-W0093-00
6F6-W0093-00-00
6F6-W0093-01
Compatible Engine Models
This Carburetor Repair Kit is primarily designed for:
2-Stroke 40HP
If you are unsure about compatibility, please provide your engine model number or identification plate for verification before ordering.
Applications
This Carburetor Repair Kit is commonly used for:
Outboard engine repair
Engine rebuilding projects
Marine maintenance workshops
Boat fleet maintenance
Commercial fishing vessels
Recreational boats
Marine spare parts distribution
