6G1-15755-00 6G1-15755-00-00
PREMARINE
| Quantity: | |
|---|---|
1. Technical Specifications
| Parameter | Specification / Detail |
| Component Type | Outboard Engine Manual Recoil Starter Grip / Pull Handle |
| OEM & Interchange Part Numbers | 6G1-15755-00-00 / 6G1-15755-00 |
| Installation Location | Manual recoil starter housing rope outlet (Starter chapter) |
| Engine Platform | Inline 1-Cylinder & 2-Cylinder 2-Stroke / 4-Stroke Marine Outboards |
| Horsepower Range | Yamaha 6HP, 8HP, 9.9HP, and 15HP models (6C, 8C, 9.9F, 15F; F6, F8, F9.9, F15) |
| Rope Compatibility | Fits standard $\Phi 3.5\text{ mm} \sim \Phi 4.5\text{ mm}$ high-tensile braided nylon starter ropes |
| Material Composition | High-density impact-modified, UV-resistant polypropylene (PP) / marine polymer |
| Operating Conditions | Resists solar UV exposure, saltwater spray, broad thermal swings, and sudden jerk loads |
2. Key Features & Functionality
Ergonomic Anti-Slip Grip: Shaped to match hand contours with textured grip surfaces, ensuring positive traction even when hands or gloves are wet with seawater or fuel mix.
UV & Impact-Resistant Polymer: Molded from heavy-duty synthetic resin that resists weathering, chalking, and snapping when rattling against the recoil bezel.
Recessed Knot Retention Chamber: Features a tapered inner rope bore leading to a deep knot cavity, locking the rope end firmly inside the handle to eliminate pull-through risks.
Flush Recoil Bezel Fitment: Base contours match OEM cowling seating recesses, keeping the handle firmly nested to prevent vibration chatter while underway.
3. Compatible Models
Primarily compatible with Yamaha portable small-displacement outboard engines:
Yamaha 2-Stroke Series: 6HP (6C, 6D), 8HP (8C), 9.9HP (9.9D, 9.9F), 15HP (15D, 15F, E15D)
Yamaha 4-Stroke Series: F6, F8, F9.9, F15 manual-start configurations
Clone Engines: Compatible with Parsun (T6 / T8 / T9.9 / T15), Hidea (HD8 / HD9.9 / HD15), Powertec, Seapro, and other outboard brands utilizing the Yamaha manual recoil starter layout
4. Aftermarket & Brand Compatibility
OEM Brand Fitment:
Yamaha Marine: Designed for genuine Yamaha 6HP through 15HP manual recoil start assemblies.
PREMARINE Brand Aftermarket Replacement:
PREMARINE Quality Standard: PREMARINE specializes in high-reliability marine recoil starter hardware, pull grips, ropes, and return springs. This starter handle is manufactured with reinforced polymers and precision injection molds.
Direct OEM-Level Performance: Tensile pull-through strength, drop-impact toughness, and weathering durability meet or exceed OEM specifications, serving as the premier cost-effective choice for replacing frayed, split, or missing starter grips.
5. Common Symptoms & Troubleshooting
Cracked, Sun-Faded, or Snapped Grip Body:
Cause: Solar UV radiation causing resin embrittlement, combined with off-axis jerk shock during startup.
Troubleshooting: Inspect the grip for hairline fractures around the rope bore; replace damaged handles immediately to avoid mid-pull breakage and hand injuries.
Rope Pulls Free from the Handle (Knot Pull-Through):
Cause: Under-sized pull rope, improper knot, or an internally worn knot chamber.
Troubleshooting: Tie a double figure-eight stop knot inside the recess; if the interior socket has stretched or worn out, replace the handle assembly.
Handle Rattles Loosely Against the Cowling Underway:
Cause: Fatigued recoil spiral spring lacking tension, or excessive rope length leaving slack.
Troubleshooting: Check recoil spring retraction force; shorten the starter rope slightly to pull the handle snugly into its resting seat.
OEM Part Numbers
Compatible OEM references include:
6G1-15755-00
6G1-15755-00-00
Compatible Engine Models
This Starter Pull Handle is primarily designed for:
2-Stroke 6/8/9.9/15HP
4-Stroke 6/8/9.9/15HP
If you are unsure about compatibility, please provide your engine model number or identification plate for verification before ordering.
Applications
This Starter Pull Handle is commonly used for:
Outboard engine repair
Engine rebuilding projects
Marine maintenance workshops
Boat fleet maintenance
Commercial fishing vessels
Recreational boats
Marine spare parts distribution
