1. Technical Specifications

2. Key Features

• High-Impact & UV-Resistant HDPE Shell: Seamless rotational/blow-molded construction offers superior puncture resistance, structural stiffness, and protection against solar degradation.

• Built-In Mechanical Fuel Gauge: Top-mounted direct-reading fuel meter provides real-time fuel level tracking (E - 1/2 - F) without requiring electrical wiring.

• Manual Venting Gas Cap: Features a precision two-way breathing screw to relieve internal vacuum during engine operation and seal tightly to prevent vapor loss during storage.

• Deep Pickup Tube with Pre-Filter: The extended internal suction tube reaches the bottom sump, fitted with a high-mesh brass strainer to prevent large sediment and debris from entering the fuel line.

3. Compatible Models

Universally compatible with Yamaha 2-stroke and 4-stroke outboards designed for portable fuel supply:

• Yamaha 2-Stroke Series: 2HP to 250HP outboards (e.g., 9.9F, 15F, 25B, 30G, 40X, 60F, 70B, 85A, 90A, etc.)

• Yamaha 4-Stroke Series: F4 to F300 outboards (e.g., F9.9, F15, F20, F25, F40, F50, F60, F70, F115, etc.)

• Aftermarket Engines: Fits Parsun, Hidea, Powertec, Tohatsu, and other brands utilizing standard Yamaha 2-prong fuel line couplers

4. Aftermarket & Brand Compatibility

• OEM Brand Fitment:

• Yamaha Marine: Designed for genuine Yamaha 24L portable fuel supply and quick-disconnect systems.

• PREMARINE Brand Aftermarket Replacement:

• PREMARINE Quality Standard: PREMARINE specializes in high-reliability marine fuel systems, portable tanks, and quick-connect fuel hardware. This fuel tank assembly is manufactured using premium UV-grade HDPE and leak-tested fittings.

• Direct OEM-Level Performance: Drop impact resilience, vacuum-sealing integrity, and ethanol resistance meet or exceed OEM specifications, serving as the premier cost-effective choice for expanding cruising range or replacing damaged tanks.

5. Common Symptoms & Troubleshooting

• Engine Starvation or Stalling at Cruising Speed:

• Cause: Gas cap vent screw remains closed (causing vacuum lock), or the bottom pickup strainer is clogged with fuel debris.

• Troubleshooting: Loosen the cap vent screw counterclockwise before starting; inspect and clean the pickup tube mesh filter.

• Fuel Leaks or Air Sucking at the Quick Connector:

• Cause: Worn O-rings inside the mating hose socket or damaged male plug pins on the tank housing.

• Troubleshooting: Inspect the male outlet fitting for fuel weepage; replace worn fuel line connectors or tank outlet adapters.

• Severe Tank Swelling or Collapsing:

• Cause: Exposure to heat with the vent closed, or a clogged two-way vent valve.

• Troubleshooting: Crack open the vent screw during high-temperature outdoor storage to equalize pressure. Replace permanently deformed tanks.

OEM Part Numbers

Compatible OEM references include:

6YJ-24201-00

6YJ-24201-20-00

6YJ-24201-21-00

Compatible Engine Models

This Fuel Tank Assembly is primarily designed for:

2-Stroke 2-250HP

4-Stroke 4-300HP

If you are unsure about compatibility, please provide your engine model number or identification plate for verification before ordering.

Applications

This Fuel Tank Assembly is commonly used for:

Outboard engine repair

Engine rebuilding projects

Marine maintenance workshops

Boat fleet maintenance

Commercial fishing vessels

Recreational boats

Marine spare parts distribution
